vector conveyors & recycling

The toughest machines in their class

Vector machines are engineered to excel in the most challenging conditions, precisely when you need them most. With over 20 years of industry experience, Vector is renowned for crafting the highest quality machines that consistently surpass industry standards.

Operating from an impressive 11-acre manufacturing facility, Vector has been at the forefront of material processing and handling systems. Their exceptional machines have contributed to successful projects across the USA, Canada, Mexico, the Caribbean, Latin America, and Africa.

The Vector by MGL range of equipment comprises a comprehensive selection, catering to material processing industries. From versatile conveyors to portable (tracked or wheeled) systems and advanced recycling systems, Vector’s lineup delivers cutting-edge solutions to meet diverse material processing needs. Count on Vector’s machines to withstand the harshest conditions and empower your operations with unparalleled performance and reliability.

conveying

Move heavy materials easily with one of Vector’s 6 various conveyors. Wheeled conveyors, track conveyors, and feeder/stackers available.

coloring & coating

Vector’s Rock and Mulching Coloring & Coating machines allow for optimal mixing of colorant prior to coating rocks or mulch.

recycling

Easily recycle materials on site with the Vector VacMax.

conveying

An American Leader in the Materials Handling Industry.

Wheeled Conveyors

General Specifications

  • Transport Length: 53’5″
  • Transport Width: 8.5’
  • Transport Height: 11′ 10″
  • Working Length: 80’
  • Working Width: 8.5’
  • Working Height (max): 35′
  • Weight (lbs.): 25,000
  • Engine: Kohler KDI 1903

Options

  • Hydraulic transport jack
  • Engine upgrade, 74HP (Kohler or Cummins)
  • Cleated belt
  • Belt scale
  • Various impact zone configurations

General Specifications

  • Transport Length: 53′ 5″
  • Transport Width: 10’
  • Transport Height: 11′ 10″
  • Working Length: 80’
  • Working Width: 10’
  • Working Height (max): 35′
  • Weight (lbs.): 20,000
  • Engine: Kohler KDI 1903

Options

  • Track dolly w/ Hydraulic transport jack
  • Engine upgrade, 74HP (Kohler or Cummins)
  • Cleated belt
  • Belt scale
  • Various impact zone configurations
  • Direct feed hopper

Track Conveyors

General Specifications

  • Transport Length: 53’5″
  • Transport Width: 8.5’
  • Transport Height: 11′ 10″
  • Working Length: 80’
  • Working Width: 8.5’
  • Working Height (max): 35′
  • Weight (lbs.): 25,000
  • Engine: Kohler KDI 1903

General Specifications

  • Transport Length: 45′ 5″
  • Transport Width: 8’
  • Transport Height: 11′ 4″
  • Working Length: 65’
  • Working Width: 8’
  • Working Height (max): 26.6′
  • Weight (lbs.): 22,000
  • Engine: Kohler KDI 1903

General Specifications

  • Transport Length: 52.2’
  • Transport Width: 8’
  • Transport Height: 8′ 11″
  • Working Length: 50’
  • Working Width: 8’
  • Working Height (max): 22’ 6″
  • Weight (lbs.): 14,000
  • Engine: Kohler KDW-1404

Feeder/Stackers

General Specifications

  • Transport Length: 57’ 8”
  • Transport Width: 10’
  • Transport Height (Axle): N/A
  • Transport Height (Low Boy): 13’
  • Working Length: 88’
  • Working Width: 10’
  • Working Height (min/max): 13’/33’ 8”
  • Weight (lbs.): 45,000
  • Engine: Perkins 1204F (110 HP)

Options

  • Anti-bridging Auger in Hopper (Mulch Applications)

coloring & coating

General Specifications

  • Total weight 48,000 lbs (approx.)
  • Transport/Overall Length 53’
  • Transport Height 13’ 6”
  • Transport/working width 8’ 6”
  • Loading height 11’ 6” – 12’ 6”
  • Loading width 16’
  • Hopper Capacity 14’ CY (approx.)
  • Anti-bridging Auger in Hopper (Mulch applications)
  • Mixing Drum Length 25’
  • Mixing Drum Diameter 7’ 4”
  • Power Unit: Cummins 2.8L 74 HP Tier 4 Engine
  • Production Capacity: 300+ YPH

Options

  • Hopper Extension
  • Full Additive Automation
  • Attached Discharge Conveyor for Increased Discharge Height
  • Electric Drives
  • Modular/Stationary Arrangements Available

Applications

  • Mulch
  • Aggregate/Sand
  • Salt

recycling

General Specifications

  • Drive: Hydraulic (15-25 GPM, 1200-2000 PSI)
  • Drive: Electric (15 HP, VFD recommended)
  • Max Fan Speed: 1200 RPM
  • Rotor Blades: HD Rubber (replaceable)
  • Standard and Custom Mounting Shrouds
  • Weight: 1050 lbs.

Options

    • 16″ x 20′ Corrugated ducting
    • Power Unit: Kohler KDW1404 24HP Diesel, skid-mounted
